Build Summary
RawMaxx CNX Container Tilt Trailer
Build Summary
RawMaxx CNX Container Tilt Trailer
At a glance ValuesPRODUCT DETAILS
Product Features
Durable Powder Coat Finish
The CNX trailer boasts a durable powder coat finish, applied after a thorough grit blast preparation. This finish provides superior protection against rust and corrosion, ensuring the trailer maintains its structural integrity over time. The powder coating extends the trailer's lifespan by protecting it from the elements.
Axles & Tires
Outfitted with two 10,000 lbs. spring axles and 6-leaf slipper spring suspension, the CNX trailer ensures a smooth ride with heavy loads. It rides on 16-inch dual black mod wheels with 10-ply radial tires rated at 3,520 lbs., providing excellent traction and durability. Electric brakes on each axle enhance safety with reliable stopping power during transit.
Hydraulic Lift System
This trailer features a robust hydraulic lift system powered by a KTI 12V pump, ensuring efficient tilt functionality. The heavy-duty scissor lift, with a 6" x 30" cylinder, provides smooth and reliable tilting at a 14° angle. Additionally, a 14' control cable makes loading and unloading equipment effortless and convenient.
Integrated Toolboxes
Designed for practicality, this trailer features a lockable front toolbox between the risers for secure and accessible storage. Additional underbody toolbox options provide extra storage capacity, making the CNX trailer highly functional for various hauling needs.
Heavy-Duty Main Frame
Constructed with a 12" x 19 lbs. I-beam main frame, the CNX trailer is built to withstand demanding hauling tasks. The frame is further reinforced with 4" x 6" x 3/16" tubing cross-members, ensuring strength and durability. This robust construction provides a solid foundation, capable of supporting heavy loads with ease.
Reliable Warranty
This RawMaxx trailer is backed by a 5-year Dexter axle warranty, a 3-year structural warranty, and a 1-year paint warranty. This comprehensive warranty package ensures that users can trust in the trailer's quality and durability over time.Description
Dimensions
- Total Length: 40'
- Tilt Deck: 40'
- Width: 102"
- Deck Height: 35"
Weight Rating
- GVWR: 20,000 lbs.
- GAWR: 10,000 lbs.
- Empty Weight: 10,450 lbs.
- Load Capacity: 12,550 lbs.
Finish
- Type: Powder Coat
- Prep: Grit Blast
- Standard Color: Jet Black
Warranty
- Axle: 5 Year Dexter
- Trailer: 3 Year Structural / 1 Year Paint
Gooseneck
- Coupler: 2-5/16” Ball Coupler
- Front Jacks: (2) Side Wind Drop Legs (10,000 lbs. capacity)
- Front Tool Box: Between Risers / Lockable Latch
- Neck Length: 96"
Safety System
- Safety Chains: 3/8" G70 Safety Chains
- Breakaway System: Electric Breakaway Kit
- Reflective Tape: 3M DOT Compliant Reflective Tape
Tilt Frame
- Flooring: 2” Treated Lumber Deck
- D-Rings: (4) D-Rings (Welded Outside Corners)
- Side Perimeter: 2" x 5" x 1/8" Tubing Outer Deck Frame
- Stake Pockets: 3-5/8" x 1-1/2" (ID) Stake Pockets
- Fenders: 3/16” Thread Plate
- Frame: 12" x 19 lbs. I-Beam Main Frame
- Cross-Members: 3" Channel / 16" Spacings
- Rear Tail: Knife Edge
Lift System
- Power: Hydraulic - Powder Up - Down
- Pump: KTI 12V Hydraulic Pump
- Controller: 14' Cable with Control
- Scissor: Heavy Duty Scissor Lift
- Cylinder: 6" x 30" Cylinder
- Tilt Angle: 14°
Main Frame
- Main Frame: 12" x 19 lbs. I-Beam Main Frame
- Cross-Members: 4" x 6" x 3/16" Tubing
Running Gear
- Tires: Radial Tires
- Size: ST235/80R16
- Ply: 10 Ply
- Rating: 3,520 lbs.
- Rims: 16” Dual Black Mod Wheels
- Bolt Pattern: 8 on 6.5”
- Suspension:
- Axle Type: Spring
- Axles: 2
- Rating: 10,000 lbs.
- Brakes: Electric
- Type: 6-Leaf Slipper Spring Suspension
Electrical & Lighting
- Wiring:
- Front Plug: 7 - Way RV
- Frame Wiring: All Weather Wiring Harness
- Lighting:
- Side Markers: 3/4" LED Bullet Lights
- Turn Flashers: 2" x 6" Amber Side Turn Lights
- Rear Lights: DOT Approved LED Lights
